Product Specification电气特性 Electrical Characteristics：
| 项目 Item | 参数值 Parameter Value |
| 电阻 Resistance (Vcc-Gnd) | 2.3KΩ ±30% / 10KΩ ±30% |
| 额定功率 Rated Power | Linear Taper B: 0.0125W |
| 额定电压 Rated Voltage | Linear Taper B: AC50V, DC5V |
| 杂音 Noise | Less than 300m Vp-p |
| 中心位分压比 Center Position Voltage | 50%±7% |
| 复位精度 Returning Accuracy Rate | ≤4.0% (Initial) |
| ≤5.5% (After Reliability Test) |
机械特性 Mechanical Characteristics：
| 项目 Item | 参数值 Parameter Value |
| 摇杆操作角度 Operation Angle of Lever | Single side: 26°Max. |
| 摇杆操作力 Operating Force of Lever | 12±5 mN·m |
| 中心按压力(开关) Center Switch Force | 7.0 ± 2.0 N |
| 中心按压行程(开关) Center Switch Travel | 0.55 +0.5/-0.4 mm |
| 摇杆复归精度 Accuracy of Reset Position of Lever | ±3° |
耐久性能 Endurance Characteristics：
| 项目 Item | 参数值 Parameter Value |
| 旋转寿命 Rotational Life | Over 2,000,000 Cycles |
| Power Value：Over 10,000,000 Cycles | |
| 开关寿命 Durability of Switch | Over 1,000,000 Cycles |
